Enamel Pin and Badge Filling Machine

This enamel pin and badge filling machine is a highly efficient and precision-engineered solution for filling resin, enamel, or similar materials into pins, badges, and jewelry products. Designed for both small-scale and industrial applications, it features a robust control system, high-speed filling capabilities, and user-friendly operation. Ideal for manufacturers of custom pins, badges, and small crafts.

Key Features:

• Dimensions: Approximately 2000mm x 1500mm x 1800mm
• Weight: 300-500 kg
• Power Supply: AC 220V, 50/60Hz
• Integrated computer control with touchscreen display
• Filling Precision: ±0.01ml
• Filling Speed: Adjustable, up to 500 pieces/hour
• Number of Nozzles: 4 automatic filling nozzles
• Multi-axis robotic arm for precision motion
• Tank Capacity: 2-5 liters per tank
• Cooling System: Air cooling
• Environmental Requirements: 0-45°C, <85% humidity
• Safety Features: Emergency stop button
• Connectivity: USB and Ethernet
• Certification: CE, ISO9001
• Warranty: 1 year

Applications:

Perfect for manufacturers of enamel pins, resin badges, small jewelry items, and crafts requiring precision filling and high productivity.
